Warranty: 10 yearsEfficient200% PV oversizing and up to 110% AC oversizing power.Higher efficiency during charging and discharging, up to 97.5% efficiencyBuilt-in shadow tracking functionEconomical16A DC single-strand DC input current, supports high-power solar panels - Up to 150% PV input power.Stores excess energy from PV into the battery.Low start-up output voltage allows the inverter to run longer.Less energy loss from battery to inverter
Intelligent
Up to 150% EPS output for 60 secondsSwitchover time <10msQuick configuration with U-discLithium-ion and lead-acid battery compatibility
CT-compatible, responds to loads within 0.3 seconds
Intelligent load management (e.g. heat pump)
Parallel on-grid and off-grid function, up to 150kW5 working modes, 2 charging periods
VPP-ready, additional service in the energy market
Three-phase unbalanced output Up to 5kW output power on single-phase output
Safe
IP65 protection level
Integrated SPD
<10Parallel operation YesSystem dataMax. efficiency [%] 98.00Euro efficiency [%] 97.7Battery charging/discharging efficiency [%] 98.5 / 97.5Protection degree IP65Operating temperature range [°C] -35~+60 (power reduction above 45C)Max. Operating altitude [m] <3000Relative operating humidity [%] 0~100Average noise [dB] <35Storage temperature [°C] -40~+70Dimensions [mm] 503×503×199Weight [kg] 30Cooling Natural coolingCommunication interface CT/Meter (optional), External controller RS485, Pocket WiFi (optional: Pocket Lan/4G), DRM, USB Upgrade, NTC (optional)Power consumptionInternal consumption (night) [W]<40W standby, <5W idleStandardsSafety EN/IEC62109-1/-2EMC EN61000-6-1/2/3/4; EN61000-3-2/3/11/12Certificate VDE4105, G99, G98, AS4777, EN50549, CEI 0-21, IEC61727, PEA/MEA, NRS-097-2-1, RD1699, TO
